Connect directly to any XR440 Data Logger input channel; no external power required.
For indoor air applications including Lab/Clean Room Pressurization, Filter Differential Pressure, Fan Static Pressure, Absolute Pressure and Barometric Pressure.
Compatible pressure media: dry air and inert gases: nitrogen, helium, neon, argon, krypton, xenon.
P300-1 inch-D Pressure Sensor (±1 inches H2O differential/gage)
Maximum P300 sensors that can connect to one XR440: Inch H2O models: 3, All other models: 4
| P300 Specifications | |
| Combined Linearity, Hysteresis & Repeatability: | ±0.5% max. |
| Maximum zero (offset) variation: (this variation can be zeroed out using Pocket Logger Software) |
15 and 30 PSI models: ±1% of full scale. 0-1 and 0-5 PSI models: ±1.6% of full scale. Inch H2O models: ±2.5% of full scale |
| Resolution: | Depends on resolution selected on XR440 Data Logger (see table below). |
| Operating temperature range: | -25 to 65°C (-13 to 149°F) |
| Compensated temperature range: | PSI models: 0 to 65°C (32 to 149°F) Inch H2O models: 5 to 50°C (41 to 122°F) |
| Maximum temperature effect over the compensated temperature range: | 15 and 30 PSI models: ±2% of full scale. 0-1 and 0-5 PSI models: ±3% of full scale. Inch H2O models: ±2% of full scale. |
| Pressure Ports: | Plastic fittings accept 3/16" I.D. tubing. |
| Power requirement (5 vdc supply): | 4 ma: PSI and Barometric models 6 ma: Inch H2O models |
| Proof / Burst Pressure: | See table of available models (below). |
| Weight: | 1.1 oz. (32 grams) |
| Overall Size: | 1.3" x 1.5" x 2.25" (33mm x 38mm x 57mm) |
Physical: Thermoplastic housing with three 12" leads.
| P300 Resolution (depends on XR440 Data Logger resolution selected) | ||||
| P300 Model | 8 bit | 10 bit | 12 bit | Units |
| ±0.4 in. H2O differential (+/-1millibar) | 0.004 | 0.001 | 0.00024 | in. H2O |
| ±1 in. H2O differential | 0.01 | 0.002 | 0.0006 | in. H2O |
| ±5 in. H2O differential | 0.05 | 0.01 | 0.003 | in. H2O |
| ±10 in. H2O differential | 0.10 | 0.02 | 0.006 | in. H2O |
| ±30 in. H2O differential | 0.29 | 0.07 | 0.018 | in. H2O |
| 0-1 psig | 0.005 | 0.001 | 0.0003 | psi |
| 0-5 psig | 0.02 | 0.006 | 0.0014 | psi |
| 0-15 psig | 0.07 | 0.017 | 0.004 | psi |
| 0-15 psia | 0.07 | 0.017 | 0.004 | psi |
| 0-30 psig | 0.13 | 0.034 | 0.009 | psi |
| 0-30 psia | 0.13 | 0.034 | 0.009 | psi |
| Barometric
600-1100 mbar |
2.4 0.08 |
0.6 0.02 |
0.15 0.005 |
mbar inHg |
Note: 1 psi = 27.677 in. H20
| P300 Pressure Sensors - available models | ||||
| RANGE | TYPE | PROOF PRESS.* | BURST PRESS. | PRICE |
| ±0.4 inch H2O (+/-1 millibar) | Differential | 100 in. H2O | 200 in. H2O | $260. |
| ±1 inch H2O | Differential | 100 in. H2O | 200 in. H2O | $210. |
| ±5 inch H2O | Differential | 150 in. H2O | 300 in. H2O | $200. |
| ±10 inch H2O | Differential | 150 in. H2O | 300 in. H2O | $200. |
| ±30 inch H2O | Differential | 150 in. H2O | 300 in. H2O | $200. |
| 0-1 psig | Gage | 20 psi | 40 psi | $160. |
| 0-5 psig | Gage | 20 psi | 40 psi | $160. |
| 0-15 psig | Gage | 30 psi | 60 psi | $160. |
| 0-15 psia | Absolute | 30 psi | 60 psi | $160. |
| 0-30 psig | Gage | 60 psi | 120 psi | $160. |
| 0-30 psia | Absolute | 60 psi | 120 psi | $160. |
| Barometric (600-1100 mbar) | Absolute | 30 psi | 60 psi | $200. |
*Exceeding the Proof Pressure causes permanent sensor failure.
P300 Sensors can be easily scaled by the user to read in any pressure unit (psi, kPa, bar, etc.). Contact Pace Scientific for details.
Part No: P300-[specify range]-[specify type]
Example part #'s: P300 for Barometric Pressure: P300-Baro; P300 Pressure Sensor for 10 inch H2O Differential: P300-10in-D
Differential models: Input range is + full scale pressure range to - full scale pressure range. For example: Pressure range for P300-10in-D is +10 inch H2O to -10 inch H2O. Differential models may also be used to read gage pressure by using the LOW port to sense ambient pressure.
Gage models: Input range is from 0 to full scale pressure range. Gage models may also be used to read differential pressure in applications where one side is always at a higher pressure. The higher pressure is connected to the Pressure port, and the lower pressure is connected to the REF (reference) port.
